SubCompact Board GENE-9455
Chapter 2 Quick Installation Guide 2-12
2.12 COM2 RI/+5V/+12V Selection (JP6)
JP6 Function
5-6 RI (Default)
3-4 +5V
1-2 +12V
2.13 LCD Backlight Voltage/PWM Control Selection (JP7)
JP7 Function
1-2 BIAS (Default)
2-3 PWM Control
2.14 AT/ATX Selection (CN22 Pin 4-5)
CN22 Pin 4-5 Function
4-5 AT (Default)
NC ATX
2.15 Audio Connector (CN1)
Pin Signal Pin Signal
1 MIC 2 MIC_Vcc
3 Ground 4 CD_GND
5 LINE_IN L 6 CD_L
7 LINE_IN R 8 CD_GND
9 Ground 10 CD_R
11 LINE_OUT L 12 LINE_OUT R
13 Ground 14 Ground
