Aaeon GENE-9455 - USB Port 3, 4 Connector (CN9); TV-Out Connector (CN10); SATA 0 Connector (CN11)

SubCompact Board GENE-9455
Chapter 2 Quick Installation Guide 2-18
2.23 USB Port 3, 4 Connector (CN9)
Pin Signal Pin Signal
1 +5 Volt. Standby 2 Ground
3 Data2- 4 Ground
5 Data2+ 6 Data3+
7 Ground 8 Data3-
9 Ground 10 +5 Volt. Standby
2.24 TV-out Connector (CN10)
Pin Signal Pin Signal
1 Y 2 CVBS
3 Ground 4 Ground
5 C 6 N/C
7 Ground 8 N/C
2.25 SATA 0 Connector (CN11)
Pin Signal
1 Ground
2 TX0+
3 TX0-
4 Ground
5 RX0-
6 RX0+
7 Ground
