Aaeon GENE-9455 - SATA 2 Connector (CN12); LVDS Connector (CN13)

SubCompact Board GENE-9455
Chapter 2 Quick Installation Guide 2-19
2.26 SATA 2 Connector (CN12)
Pin Signal
1 Ground
2 TX1+
3 TX1-
4 Ground
5 RX1-
6 RX1+
7 Ground
2.27 LVDS Connector (CN13)
Pin Signal Pin Signal
1 Back-Light Enable 2 Back-Light Control / N/C
3 LCD Volt. 4 Ground
5 LA_CLK# 6 LA_CLK
7 LCD Volt. 8 Ground
9 LA_DATA#_0 10 LA_DATA_0
11 LA_DATA#_1 12 LA_DATA_1
13 LA_DATA#_2 14 LA_DATA_2
15 N/C 16 N/C
17 LVDS_DATA / N/C 18 LVDS_CLK / N/C
19 LB_DATA#_0 20 LB_DATA_0
21 LB_DATA#_1 22 LB_DATA_1
23 LB_DATA#_2 24 LB_DATA_2
25 N/C 26 N/C
27 LCD Volt. 28 Ground
29 LB_CLK# 30 LB_CLK
