Aaeon GENE-9455 - CPU Fan Connector (CN25); 12 V Output Connector (CN26); Compactflash Disk (CFD1)

SubCompact Board GENE-9455
Chapter 2 Quick Installation Guide 2-25
3 Ground
4 +5 Volt.
2.39 CPU Fan Connector (CN25)
Pin Signal
1 Ground
2 +5 Volt. (Optional) / +12 Volt.
3 FAN Sense
2.40 +5V/+12V Output Connector (CN26)
Pin Signal
1 +12 Volt.
2 Ground
3 Ground
4 +5 Volt.
2.41 CompactFlash Disk (CFD1)
Pin Signal Pin Signal
1 Ground 26 Ground
2 PDD3 27 PDD11
3 PDD4 28 PDD12
4 PDD5 29 PDD13
5 PDD6 30 PDD14
6 PDD7 31 PDD15
7 PDCS#1 32 PDCS#3
8 Ground 33 Ground
9 Ground 34 PDIOR#
10 Ground 35 PDIOW#
