SubCompact Board GENE-9455
Chapter 2 Quick Installation Guide 2-13
2.16 AAEON Expansion Slot (CN2)
Pin Signal Pin Signal
1 +2.5 Volt. 2 SDVO_CLK#
3 +2.5 Volt. 4 SDVO_CLK
5 +2.5 Volt. 6 Ground
7 RI# 8 SDVO_BLUE#
9 SERIRQ# 10 SDVO_BLUE
11 PCI_RST# 12 SDVO_GREEN#
13 PCI_GNT#2 14 SDVO_GREEN
15 PCI_GNT#1 16 SDVO_RED#
17 PCI_AD11 18 SDVO_RED
19 PCI_AD13 20 Ground
21 PCI_TRDY# 22 SDVO_INT#
23 PCI_FRAME# 24 SDVO_INT
25 PCI_AD24 26 Ground
27 PCI_INT#C 28 SDVOCTRL_CLK
29 PCI_PME# 30 SDVOCTRL_DATA
31 PCI_AD28 32 SDVO_FLDSTALL#
33 PCI_REQ#1 34 SDVO_FLDSTALL
35 PCI_AD22 36 Ground
37 PCI_PAR 38 +5 Volt.
39 PCI_INT#D 40 +5 Volt.
41 PCICLK2_IN 42 +5 Volt.
43 PCICLK1_IN 44 Ground
45 PCI_AD16 46 SMBCLK
47 PCI_REQ#2 48 SMBDATA
49 PCI_AD26 50 Ground
To Next Page
