SubCompact Board GENE-9455
Chapter 2 Quick Installation Guide 2-14
51 PCI_AD30 52 PCIE_WAKE#
53 PCI_AD31 54 PCIE_RST#
55 PCI_AD29 56 Ground
57 PCI_STOP# 58 PCIE_TXP
59 PCI_AD18 60 PCIE_TXN
61 PCI_AD27 62 PCIE_RXP
63 PCI_AD25 64 PCIE_RXN
65 PCI_C/BE#0 66 Ground
67 IDSEL2 – ( PCI_AD27 ) 68 PCIE_CLK
69 PCI_C/BE#3 70 PCIE_CLK#
71 PCI_AD23 72 Ground
73 IDSEL1 – ( PCI_AD25 ) 74 LPC_AD3
75 PCI_AD20 76 LPC_AD2
77 PCI_DEVSEL# 78 LPC_AD1
79 PCI_AD21 80 LPC_AD0
81 PCI_AD19 82 LPC_DRQ#
83 PCI_AD17 84 LPC_FRAME#
85 PCI_C/BE#2 86 Ground
87 PCI_IRDY# 88 +3.3 Volt. Standby
89 PCI_AD4 90 +3.3 Volt. Standby
91 PCI_AD9 92 +3.3 Volt. Standby
93 PCI_AD15 94 Ground
95 PCI_CLKRUN# 96 SLP_S3#
97 PCI_SERR# 98 SLP_S4#
99 PCI_AD6 100 SLP_S5#
101 PCI_PERR# 102 N/C
103 PCI_C/BE#1 104 +5 Volt. Standby
105 PCI_AD0 106 +5 Volt. Standby
To Next Page
