SubCompact Board GENE-9455
Chapter 2 Quick Installation Guide 2-17
29 DACK# 30 Ground
31 IRQ14 32 N/C
33 A1 34 Cable Detect
35 A0 36 A2
37 CS#1 38 CS#3
39 ACT# 40 Ground
2.21 RJ-45 Ethernet #2 Connector (CN7)
Pin Signal Pin Signal
1 MDI2_0+ / TXD+ 2 MDI2_0- / TXD-
3 MDI2_1+ / RXD+ 4 MDI2_1- / RXD-
5 TCD2_0 6 TCD2_1
7 MDI2_2+ 8 MDI2_2-
9 MDI2_3+ 10 MDI2_3-
11 ACT_2_LED 12 +3.3 Volt.
13 SPD100_2_LED 14 SPD1G_2_LED
2.22 RJ-45 Ethernet #1 Connector (CN8)
Pin Signal Pin Signal
1 MDI1_0+ / TXD+ 2 MDI1_0- / TXD-
3 MDI1_1+ / RXD+ 4 MDI1_1- / RXD-
5 TCD1_0 6 TCD1_1
7 MDI1_2+ 8 MDI1_2-
9 MDI1_3+ 10 MDI1_3-
11 ACT_1_LED 12 +3.3 Volt.
13 SPD100_1_LED 14 SPD1G_1_LED
To Next Page
