SubCompact Board GENE-9455
Chapter 2 Quick Installation Guide 2-11
2.7 Clear CMOS (JP1)
JP1 Function
1-2 Normal (Default)
2-3 Clear CMOS
2.8 Front Panel (JP2)
JP2 Function
(-)1-2(+) ATX Power-on Button
(-)3-4(+) HDD Active LED
(-)5-6(+) External Speaker
(-)7-8(+) Power LED
(-)9-10(+) System Reset Button
2.9 Touch Screen 4/5/8-wire Mode Selection (Optional)(JP3)
JP3 Function
1-2 4, 8 wire (Default)
NC 5 wire
2.10 LVDS Operating Voltage Selection (JP4)
JP4 Function
1-2 +5V
2-3 +3.3V (Default)
2.11 LCD Backlight Voltage Selection (JP5)
JP5 Function
1-2 +12V
2-3 +5V (Default)
