SubCompact Board GENE-9455
Chapter 2 Quick Installation Guide 2-24
2.35 Onboard BIOS Programming I/F (CN21)
P
in Signal Pin Signal
1 +3.3 Volt. 2 Ground
3 SPI_CE# 4 SPI_CLK
5 SPI_SO 6 SPI_SI
7 N/C 8 N/C
2.36 ATX Connector (CN22)
Pin Signal
1 N/C
2 Ground
3 N/C
4 Ground
5 PS_ON#
6 +5 Volt. Standby
2.37 Wide Range Voltage Input Connector (CN23)- Configured by
manufacturer
Pin Signal
1 Vin (+8.5~+19 Volt.)
2 Ground
2.38 +5V Power Input Connector (CN24)- Configured by
manufacturer
Pin Signal
1 N/C
2 Ground
