Aaeon GENE-9455 - Page 64

SubCompact Board GENE-9455
Appendix C Mating Connector C - 3
CN18
COM Port 4
Connector
Neltron 2026B-10
Serial
Port
Cable
1701100206
CN20
Digital I/O
Connector
Neltron 2026B-10 N/A
CN22
ATX
Connector
Catch 2418HJ-06
ATX
External
5VSB
Cable
1702200205
CN24
+5V Power
Input
Connector
Neltron 8980-04 N/A
CN25
CPU Fan
Connector
Catch
1190-700-03
S
N/A
N/A
CN26
+5V/+12V
Output
Connector
HoBase 2543-H-4
SATA
Power
Cable
1702151200
