1.3 Specifications
System
l CPU: Socket 370 based VIA C3 and
Intel® Celeron and Pentium®III
/III(Tualatin) Processors to 1.4GHz
l Memory: SDRAM DIMM Socket x 1, Max
512MB (PC-100/133 supported)
l Socket: 370 Pin Socket
l Chipset: VIA Twister-T VT8606T
l Chipset I/O: VIA 82686B/Winbond W83977TF
l BIOS: Award 2 Mb FLASH BIOS
l Audio: ALC201A Codec AC97, Mic in, Line
in, Line out
l SSD: One 32 Pin DIP socket supports
M-systems Disk On Chip 2000
Series up to 144MB
l CF: One CF Type II socket supports
Type I/II
l Watchdog timer: Can generate a system Reset, IRQ 15
or NMI. Software selectable
time-out interval (1sec~255 sec,
1sec/step )
l DMA: 7 DMA channels (8237 equivalent)
l PCI: PCI Ver. 2.2 compliant interface
