Aaeon PCM-6893 - Compact Flash Connector Standard (CF1)

Compact Board PCM- 6893
Chapter 2 Quick Installation Guide
2 - 24
2.31 Compact Flash Connector Standard (CF1)
Pin Signal Pin Signal
1 GND 26 GND
2 DATA3 27 DATA11
3 DATA4 28 DATA12
4 DATA5 29 DATA13
5 DATA6 30 DATA14
6 DATA7 31 DATA15
7 CS#1 32 CS#3
8 GND 33 GND
9 GND 34 IO READ
10 GND 35 IO WRITE
11 GND 36 VCC5
12 GND 37 IRQ15
13 VCC5 38 VCC5
14 GND 39 CSEL
15 GND 40 N.C
16 GND 41 IDE RESET
17 GND 42 IO READY
18 ADDR2 43 N.C
19 ADDR1 44 VCC5
20 ADDR0 45 DASP
21 DATA0 46 DIAG
22 DATA1 47 DATA8
23 DATA2 48 DATA9
24 N.C 49 DATA10
25 GND 50 GND
