Compact Board PCM- 6893
Chapter 2 Quick Installation Guide
2 - 21
19 ENBKL 20 N.C
2.28 LVDS Connector (LVDS2)
Pin Signal Pin Signal
1 TX2OUT1 2 TX2OUT1#
3 GND 4 GND
5 TX2CLK 6 TX2CLK#
7 GND 8 VCC
9 VCC 10 VCC
11 TX2OUT2 12 TX2OUT2#
13 GND 14 GND
15 TX2OUT0 16 TX2OUT0#
17 N.C 18 N.C
2.29 10/100Base-Tx Ethernet Connector (LAN1)
This 10/100Base-Tx Ethernet connector is a standard RJ-45
connector. The onboard REALTEL 8139C Fast Ethernet controller
supports 10Mb/s and 100 Mb/s N-way auto-negotiation operations.
Pin Signal Pin Signal
1 TX+ 2 TX-
3 RX+ 4 N.C
5 N.C 6 RX-
7 N.C 8 N.C
