Compact Board PCM- 6893
Chapter 2 Quick Installation Guide
2 - 27
25 SLCT 26 GND
2.36 Wake On Lan / Ring Connector (WOL1)
Pin Signal
1 5VSB
2 GND
3 WAKE UP
2.37 Floppy Connector Standard
With support of Standard types of floppy, you can simply adopt any
of the combinations of 5.25" (360 KB and 1.2 MB) and/or 3.5" (720
KB, 1.44 MB, and 2.88 MB) drives onto the mainboard.
A 34-pin daisy-chain drive connector cable is required for a
dual-drive system. On one end of the cable is a 34-pin flat-cable
connector. On the other end are two sets of floppy disk drive
connectors. Each set consists of a 34-pin flat-cable connector
(usually used for 3.5" drives) and a printed-circuit board connector
(usually used for 5.25" drives). Wire number 1 on the cable is
normally red or blue, and the other wires are usually gray.
Connecting the floppy drive
1. Plug the 34-pin flat-cable connector into FDC1. Make sure that
the red or blue wire corresponds to pin 1 on the connector.
2. Attach the appropriate connector on the other end of the cable
to the floppy drive(s). You can use only one connector in the set.
The set on the end (after the twist in the cable) connects to A: drive.
The set in the middle connects to B: drive.
3. If you are connecting a 5.25" floppy drive, line up the slot in the
printed circuit board with the blocked-off part of the cable
connector.
