Aaeon PCM-6893 - Table of Contents

Compact Board PCM- 6893
iv
Contents
Chapter 1 General Information
1.1 Introduction.........................................................................................1-2
1.2 Features................................................................................................ 1-3
1.3 Specifications....................................................................................... 1-4
Chapter 2 Quick Installation Guide
2.1 Safety Precautions...............................................................................2-2
2.2 Location of Connectors and Jumpers............................................. 2-3
2.3 Mechanical Drawing...........................................................................2-5
2.4 List of Jumpers.................................................................................... 2-7
2.5 List of Connectors.............................................................................. 2-8
2.6 Setting Jumpers...................................................................................2-10
2.7 LVDS Voltage Select (J1)................................................................2-11
2.8 LCD SHIFT CLOCK Select (J2) ..................................................2-11
2.9 DOC ADDRESS Select (J3) ......................................................... 2-12
2.10 WDT Status Setup (J4) .................................................................2-12
2.11 Serial Port 3 RING Status Setup (J5) ........................................ 2-13
2.12 Serial Port 4 RING Status Setup (J6) ........................................ 2-13
2.13 Serial Port 2 Status Setup (J7) ......................................................2-13
2.14 Serial Port 2 Status Setup (J8) ......................................................2-14
2.15 Serial Port 2 Status Setup (J9) ..................................................... 2-14
2.16 COMS Status Setup (JBAT1) .......................................................2-15
2.17 TV Output Connector (CN1) ......................................................2-15
2.18 LAN1 Status Connector (CN2) ................................................... 2-15
