2.16 COMS Status Setup (JBAT1)
JBAT1 Function
1-2 Normal *
2-3 Clear CMOS
* default setting
Warning:
To avoid damaging the computer, always turn off the power supply
before setting “ Clear CMOS.” Before turning on the power
supply, set the jumper back to “Protected”
2.17 TV Output Connector (CN1)
Pin Signal Pin Signal
1 Y-OUT 2 COMP
3 GND 4 GND
5 C-OUT 6 N.C
7 GND 8 N.C
2.18 LAN1 Status Connector (CN2)
The PCM-6893 supports three sets of LED connector for external
LED indicators.
Ethernet active signal LED
Flashing Tx or Rx LEDs indicate that the PCM-6893 is transmitting
or receiving data.
