Aaeon PCM-6893 - LVDS Voltage Select (J1); LCD SHIFT CLOCK Select (J2)

Compact Board PCM- 6893
Chapter 2 Quick Installation Guide
2 - 11
2.7 LVDS Voltage Select (J1)
You can select the LVDS voltage situation by setting J1. The following chart
shows the available options.
J1 Function
1-2 +5V
2-3 +3.3V *
* default setting
2.8 LCD SHIFT CLOCK Select (J2)
You can select the LVDS clock situation by setting J2. The following chart
shows the available options.
J2 Function
1-2 SHCLK *
2-3 -SHCLK
* default setting
