Aaeon PCM-6893 - DOC ADDRESS Select (J3); WDT Status Setup (J4)

Compact Board PCM- 6893
Chapter 2 Quick Installation Guide
2 - 12
2.9 DOC ADDRESS Select (J3)
J3 ADDRESS
1-2(Open)
3-4(Open)
D400 *
1-2(Open)
3-4(Close)
D800
1-2(Close)
3-4(Open)
DC00
1-2(Close)
3-4(Close)
DISABLE
* default setting
2.10 WDT Status Setup (J4)
J4 Function
1-2 Reset *
3-4 MNI
5-6 IRQ15
* default setting
