2.34 CPU Fan Connector (FAN1)
You can attach one cooler on the CPU and the chassis respectively
to diffuse heat more efficiently. The pin assignments of the one-fan
connectors are identical. See the following table for details.
Pin Signal
1 GND
2 +12V
3 SENSOR
2.35 Printer Port Connector (LPT1)
Normally, the parallel port is used to connect the board to a printer.
The PCM-6893 includes a multi-mode (ECP/EPP/SPP) parallel port.
It is accessed via LPT1 with a 26-pin flat-cable connector.
You will need an adapter cable if you use a traditional DB-25
connector. The adopter cable should have a 26-pin connector on one
end and a DB-25 connector on the other end.
Pin Signal Pin Signal
1 LPT_STB 2 AUTOFD
3 LPT_D0 4 ERROR
5 LPT_D1 6 INIT
7 LPT_D2 8 SLCTIN
9 LPT_D3 10 GND
11 LPT_D4 12 GND
13 LPT_D5 14 GND
15 LPT_D6 16 GND
17 LPT_D7 18 GND
19 ACK 20 GND
21 BUSY 22 GND
23 PE 24 GND
