Aaeon PCM-6893 - ATX Power Connectors (PWR1); AT Power Connector (PWR2)

Compact Board PCM- 6893
Chapter 2 Quick Installation Guide
2 - 25
2.32 ATX Power Connectors (PWR1)
Pin Signal Pin Signal
1 +3.3V 11 +3.3V
2 +3.3V 12 -12V
3 GND 13 GND
4 +5V 14 PS-ON
5 GND 15 GND
6 +5V 16 GND
7 GND 17 GND
8 PWR-OK 18 -5V
9 5VSB 19 +5V
10 +12V 20 +5V
2.33 AT Power Connector (PWR2)
Pin Signal
1 PWR-OK
2 +5V
3 +12V
4 -12V
5 GND
6 GND
7 GND
8 GND
9 -5V
10 +5V
11 +5V
12 +5V
