Aaeon PCM-6893 - Page 37

Compact Board PCM- 6893
Chapter 2 Quick Installation Guide
2 - 23
29 DDACKA 30 GND
31 IRQ14 32 N.C.
33 PDA1 34 UDMA DETECT
35 PDA0 36 PDA2
37 PDCS1 38 PDCS3
39 HDLED 40 GND
41 VCC5 42 VCC5
43 GND 44 N.C
