AAON RN Series Installation, Operation & Maintanance Manual

18
RN Series Feature String Nomenclature
:
SIZE
VLT
CONFIG
A1
A2
A3
A4
B1
B2
B3
1A
1B
1C
1D
2
3
4
5A
5B
5C
6A
6B
6C
7
8
9
10
11
12
13
14A
14B
15
16
17
18
19
20
21
22
23
R
N
–
0 2 5
–
3
– 0
–
B
B
0 2
– 3 8 4 :
A
0 0 0 –
D
0
B
–
D
E
H
– 0
B
A
– 0
D
0 0 0 0
L
–
0 0
– 0 0
B
0 0 0 0 0
B
GEN
Model Options
Unit Feature Options
Feature 5: SUPPLY AIR OPTIONS
0 = 1 Blower + Standard Eff. Motor
5A: SUPPLY AIR BLOWER CONFIGURATION
A = 2 Blowers + Standard Eff. Motors
B = 1 Blower + Premium Eff. Motor
C = 2 Blowers + Premium Eff. Motors
D = 1 Blower + Premium Eff. + 1 VFD
F = 2 Blowers + Premium Eff. + 1 VFD
G = 2 Blowers + Premium Eff. + 2 VFDs
B = 15” Backward Curved Plenum
5B: SUPPLY AIR BLOWER
C = 18.5” Backward Curved Plenum
D = 24” Backward Curved Plenum
E = 27” Backward Curved Plenum
F = 30” BC Plenum - 90% Width + 1750 rpm Max -
Aluminum Wheel
G = 15” BC Plenum - 70% Width
H = 18.5” BC Plenum - 70% Width
J = 18.5” Backward Curved Plenum
K = 18.5” BC Plenum - 60% Width
L = 30” BC Plenum - 1600 rpm Max - Aluminum
Wheel
M = 13.5” Backward Curved Plenum
N = 13.5” BC Plenum - 70% Width
P = 24” BC Plenum - 60% Width
Q = 27” BC Plenum - 60% Width
R = 22” Backward Curved Plenum
S = 22” BC Plenum - 70% Width
T = 17” Backward Curved Plenum
U = 17” BC Plenum - 70% Width
V = 33” Backward Curved Plenum
W = 36.5” Backward Curved Plenum
Y = 42.5” Backward Curved Plenum
C = 1 hp - 1760 rpm
5C: SUPPLY AIR BLOWER MOTOR
D = 2 hp - 1760 rpm
E = 3 hp - 1760 rpm
F = 5 hp - 1760 rpm
G = 7.5 hp - 1760 rpm
H = 10 hp - 1760 rpm
L = 15 hp - 1760 rpm
M = 20 hp - 1760 rpm
N = 1 hp - 1170 rpm
P = 2 hp - 1170 rpm
Q = 3 hp - 1170 rpm
R = 5 hp - 1170 rpm
S = 7.5 hp - 1170 rpm
T = 10 hp - 1170 rpm
U = 15 hp - 1170 rpm
V = 20 hp - 1170 rpm
W = 25 hp - 1170 rpm
Y = 30 hp - 1170 rpm
3 = 25 hp - 1760 rpm
4 = 30 hp - 1760 rpm
5 = 40 hp - 1760 rpm
6 = 50 hp - 1760 rpm
Feature 6: FILTERS
0 = Standard - None
6A: PRE FILTER
A = 2” Pleated - 30% Eff. - MERV 8
B = Metal Mesh Outside Air Filter
C = Lint Screen Filter
D = Exhaust Air ERW Filter
F = Options A + D
G = Options B + D
H = Options A + B + D
0 = 2” Throwaway
6B: UNIT FILTER
or 2” Pleated - 30% Eff. - MERV 8
A = 2” Pleated - 30% Eff. - MERV 8
B = 4” Pleated - 30% Eff. - MERV 8
C = 2” Permanent Filter + Replaceable Media
F = 4” Pleated - 65% Eff. - MERV 11
G = 4” Pleated - 85% Eff. - MERV 13
H = 4” Pleated - 95% Eff. - MERV 14

AAON RN Series Specifications

General

Category	Heat Pump
HSPF	Up to 10.0
Refrigerant	R-410A
Compressor Type	Scroll
Efficiency	High
Series	RN
Voltage Options	208-230/460V
Unit Weight	Varies with model
Dimensions	Varies with model
