AAON RN Series Installation, Operation & Maintanance Manual

19
RN Series Feature String Nomenclature
:
SIZE
VLT
CONFIG
A1
A2
A3
A4
B1
B2
B3
1A
1B
1C
1D
2
3
4
5A
5B
5C
6A
6B
6C
7
8
9
10
11
12
13
14A
14B
15
16
17
18
19
20
21
22
23
R
N
– 0 2 5 – 3 – 0 –
B
B
0 2 –
3 8 4 :
A
0 0 0
–
D
0
B
–
D
E
H
–
0
B
A
–
0
D
0 0 0 0
L
– 0 0 – 0 0
B
0 0 0 0 0
B
GEN
Model Options
Unit Feature Options
0 = Standard
6C: FILTER OPTIONS
A = Clogged Filter Switch
B = Magnehelic Gauge
C = Options A + B
0 = Standard
Feature 7: REFRIGERATION
CONTROL
A = 5 Min. Time Delay Relay - Comp. Off
B = 20 Sec. Time Delay Relay - Comp. Staging
C = Fan Cycling
D = Adjustable Lockouts - Each Circuit
E = Freeze Stats - Each Circuit
F = Options A + B
G = Options A + C
H = Options A + D
J = Options A + E
K = Options B + C
L = Options B + D
M = Options B + E
N = Options C + D
P = Options C + E
Q = Options D + E
R = Options A + B + C
S = Options A + B + D
T = Options A + B + E
U = Options A + C + D
V = Options A + C + E
W = Options A + D + E
Y = Options B + C + D
Z = Options B + C + E
1 = Options B + D + E
2 = Options C + D + E
3 = Options A + B + C + D
4 = Options A + B + C + E
5 = Options A + B + D + E
6 = Options A + C + D + E
7 = Options B + C + D + E
8 = Options A + B + C + D + E
0 = Standard
Feature 8: REFRIGERATION OPTIONS
A = Hot Gas Bypass Lead Stage
or Hot Gas Bypass Lag Stage with Lead Variable
Capacity Compressor
B = Hot Gas Bypass Lead and Lag Stages
C = Hot Gas Reheat
D = Modulating Hot Gas Reheat
E = 0°F Low Ambient Lead Stage
F = Options A + C
G = Options B + C
H = Options A + D
J = Options B + D
K = Options A + E
L = Options B + E
0 = Standard
Feature 9: REFRIGERATION
ACCESSORIES
A = Sight Glass
B = Compressor Isolation Valves
C = Options A + B
D = ECM Condenser Fan - Multiple Speed
E = ECM Condenser Fan - Head Pressure Control
F = VFD Controlled Condenser Fans - Variable
Speed
G = Options A + D
H = Options B + D
J = Options A + B + D
K = Options A + E
L = Options B + E
M = Options A + B + E
N = Options A + F
P = Options B + F
Q = Options C + F
0 = Standard Power Block
Feature 10: POWER OPTIONS
A = 100 Amp Power Switch
B = 150 Amp Power Switch
C = 225 Amp Power Switch
D = 400 Amp Power Switch
E = 600 Amp Power Switch
F = 60 Amp Power Switch
5 = 800 Amp Power Switch
6 = 1200 Amp Power Switch

AAON RN Series Specifications

General

Category	Heat Pump
HSPF	Up to 10.0
Refrigerant	R-410A
Compressor Type	Scroll
Efficiency	High
Series	RN
Voltage Options	208-230/460V
Unit Weight	Varies with model
Dimensions	Varies with model
