78VCCX2 Controller Technical Guide
APPENDIX C: BACNET GUIDE
Analog Inputs
VCCX2 ANALOG INPUTS
Parameter Object Description Limits
RSMZ 5 Comp Alarms 2 AI: 226 Current RSMZ 5 Comp VFD Alarms 2 See RSMZ Alarms 2 Bits on page 92.
RSMZ 5 Comp VFD Drive
Status
AI: 227 Current RSMZ 5 Comp VFD drive status See RSMZ Drive Status Bits on page 91.
RSMZ 5 Compressor Current AI: 228 Current reading in Amps that the RSMZ 5 compressor is
using
RSMZ 5 Discharge Line Temp AI: 229 Current RSMZ 5 discharge line temperature
RSMZ 5 Faults AI: 230 Current RSMZ 5 Faults See RSMZ Faults Bits on page 91.
RSMZ 5 Lockouts AI: 231 Current RSMZ 5Lockouts See RSMZ Lockouts Bits on page 91.
RSMZ 6 Condenser Fan AI: 232 Current RSMZ 6 condenser fan signal
RSMZ 6 Reheat Valve 1 AI: 233 Current RSMZ 6 Reheat Valve 1 position
RSMZ 6 Discharge Pressure AI: 234 Current RSMZ 6 discharge pressure
RSMZ 6 Suction Pressure AI: 235 Current RSMZ 6 Suction Pressure
RSMZ 6 Suction Line Temp AI: 236 Current RSMZ 6 Suction Line Temperature
RSMZ 6 Saturation Temp AI: 237 Current RSMZ 6 Saturation Temperature
RSMZ 6 Superheat AI: 238 Current RSMZ 6 Superheat Temperature
RSMZ 6 EEV Position AI: 239 Current RSMZ 6 EEV valve position
RSMZ 6 Suction Pressure 2 AI: 240 Current RSMZ 6 Suction pressure 2
RSMZ 6 Suction Line Temp 2 AI: 241 Current RSMZ 6 Suction Line Temperature 2
RSMZ 6 Saturation Temp 2 AI: 242 Current RSMZ 6 Saturation Temperature 2
RSMZ 6 Superheat 2 AI: 243 Current RSMZ 6 Superheat Temperature 2
RSMZ 6 EEV Position 2 AI: 244 Current RSMZ 6 EEV valve position 2
RSMZ 6 Warnings AI: 245 Current RSMZ 6 Warnings See RSMZ Warnings Bits on page 91.
RSMZ 6 Discharge Line Temp AI: 246 Current RSMZ 6 discharge line temperature
RSMZ 6 Faults AI: 247 Current RSMZ 6 Faults See RSMZ Faults Bits on page 91.
RSMZ 6 Lockouts AI: 248 Current RSMZ 6 Lockouts See RSMZ Lockouts Bits on page 91.
Not used AI: 249 Not used
Not used AI: 250 Not used
Not used AI: 251 Not used
Not used AI: 252 Not used
SUB 1 Sub Cool 1 AI: 253 Current Subcooling Module 1 Sub Cool 1 reading
SUB 1 Sub Cool 2 AI: 254 Current Subcooling Module 1 Sub Cool 2 reading
SUB 1 Sub Cool 3 AI: 255 Current Subcooling Module 1 Sub Cool 3 reading
SUB 1 Pressure 1 AI: 256 Current Subcooling Module 1 liquid line pressure 1 reading
SUB 1 Pressure 2 AI: 257 Current Subcooling Module 1 liquid line pressure 2 reading
SUB 1 Pressure 3 AI: 258 Current Subcooling Module 1 liquid line pressure 3 reading
SUB 1 Saturation 1 AI: 259 Subcooling Module 1 saturation temperature 1 reading
SUB 1 Saturation 2 AI: 260 Subcooling Module 1 saturation temperature 2 reading
SUB 1 Saturation 3 AI: 261 Subcooling Module 1 saturation temperature 3 reading
SUB 1 Line Temp 1 AI: 262 Subcooling Module 1 liquid line temperature 1 reading
SUB 1 Line Temp 2 AI: 263 Subcooling Module 1 liquid line temperature 2 reading
SUB 1 Line Temp 3 AI: 264 Subcooling Module 1 liquid line temperature 3 reading
SUB 2 Sub Cool 1 AI: 265 Current Subcooling Module 2 Sub Cool 1 reading
SUB 2 Sub Cool 2 AI: 266 Current Subcooling Module 2 Sub Cool 2 reading
SUB 2 Sub Cool 3 AI: 267 Current Subcooling Module 2 Sub Cool 3 reading
Objects labeled AI are read-only.
