77VCCX2 Controller Technical Guide
APPENDIX C: BACNET GUIDE
Analog Inputs
VCCX2 ANALOG INPUTS
Parameter Object Description Limits
RSMZ 3 Reheat Valve 1 AI: 184 Current RSMZ 3 Reheat Valve 1 position
RSMZ 3 Discharge Pressure AI: 185 Current RSMZ 3 discharge pressure
RSMZ 3 Suction Pressure AI: 186 Current RSMZ 3 Suction Pressure
RSMZ 3 Suction Line Temp AI: 187 Current RSMZ 3 Suction Line Temperature
RSMZ 3 Saturation Temp AI: 188 Current RSMZ 3 Saturation Temperature
RSMZ 3 Superheat AI: 189 Current RSMZ 3 Superheat temperature
RSMZ 3 EEV Position AI: 190 Current RSMZ 3 EEV valve position
RSMZ 3 Suction Pressure 2 AI: 191 Current RSMZ 3 Suction pressure 2
RSMZ 3 Suction Line Temp 2 AI: 192 Current RSMZ 3 Suction Line Temperature 2
RSMZ 3 Saturation Temp 2 AI: 193 Current RSMZ 3 Saturation Temperature 2
RSMZ 3 Superheat 2 AI: 194 Current RSMZ 3 Superheat Temperature 2
RSMZ 3 EEV Position 2 AI: 195 Current RSMZ 3 EEV valve position 2
RSMZ 3 Warnings AI: 196 Current RSMZ 3 Warnings See RSMZ Warnings Bits on page 91.
RSMZ 3 Discharge Line Temp AI: 197 Current RSMZ 3 discharge line temperature
RSMZ 3 Faults AI: 198 Current RSMZ 3 Faults See RSMZ Faults Bits on page 91.
RSMZ 3 Lockouts AI: 199 Current RSMZ 3 Lockouts See RSMZ Lockouts Bits on page 91.
RSMZ 4 Condenser Fan AI: 200 Current RSMZ 4 Condenser Fan Signal
RSMZ 4 VFD Comp Perc AI: 201 Current RSMZ 4 VFD Compressor Percentage
RSMZ 4 Discharge Pressure AI: 202 Current RSMZ 4 Discharge Pressure
RSMZ 4 Suction Pressure AI: 203 Current RSMZ 4 Suction Pressure
RSMZ 4 Suction Line Temp AI: 204 Current RSMZ 4 Suction Line Temperature
RSMZ 4 Saturation Temp AI: 205 Current RSMZ 4 Saturation Temperature
RSMZ 4 Superheat AI: 206 Current RSMZ 4 Superheat Temperature
RSMZ 4 EEV Position AI: 207 Current RSMZ 4 EEV valve position
RSMZ 4 Warnings AI: 208 Current RSMZ 4 Warnings See RSMZ Warnings Bits on page 91.
RSMZ 4 Comp VFD Alarms 1 AI: 209 Current RSMZ 4 Comp VFD Alarms 1 See RSMZ Alarms 1 Bits on page 92.
RSMZ 4 Comp VFD Alarms 2 AI: 210 Current RSMZ 4 Comp VFD Alarms 2 See RSMZ Alarms 2 Bits on page 92.
RSMZ 4 Comp VFD Drive
Status
AI: 211 Current RSMZ 4 Comp VFD drive status See RSMZ Drive Status Bits on page 91.
RSMZ 4 Comp VFD
Compressor Current
AI: 212 Current reading in Amps that the RSMZ 4 compressor is
using
RSMZ 4 Discharge Line Temp AI: 213 Current RSMZ 4 discharge line temperature
RSMZ 4 Faults AI: 214 Current RSMZ 4 Faults See RSMZ Faults Bits on page 91.
RSMZ 4 Lockouts AI: 215 Current RSMZ 4 Lockouts See RSMZ Lockouts Bits on page 91.
RSMZ 5 Condenser Fan AI: 216 Current RSMZ 5 Condenser Fan Signal
RSMZ 5 VFD Comp Perc AI: 217 Current RSMZ 5 VFD Compressor Percentage
RSMZ 5 Discharge Pressure AI: 218 Current RSMZ 5 discharge pressure
RSMZ 5 Suction Pressure AI: 219 Current RSMZ 5 Suction pressure
RSMZ 5 Suction Line Temp AI: 220 Current RSMZ 5 Suction Line Temperature
RSMZ 5 Saturation Temp AI: 221 Current RSMZ 5 Saturation Temperature
RSMZ 5 Superheat AI: 222 Current RSMZ5 Superheat temperature
RSMZ 5 EEV Position AI: 223 Current RSMZ 5 EEV valve position
RSMZ 5 Warnings AI: 224 Current RSMZ 5 Warnings See RSMZ Warnings Bits on page 91.
RSMZ 5 Comp VFD Alarms 1 AI: 225 Current RSMZ 5 Comp VFD Alarms 1 See RSMZ Alarms 1 Bits on page 92.
Objects labeled AI are read-only.
