Page 38 01/2007 AMT/PTD/PBX/0020/2/4/EN
Definition of the debug screen corresponding to other base stations detected by the
mobile terminal
Figure 2-8: Debug screen for other base stations detected by the M90x mobile terminal
• C3C3/R3R3: RPN and RSSI
Indicates the third best available base station for handover in cell XX
• C4C4/R4R4: RPN and RSSI
Indicates the fourth best available base station for handover in cell XX
• C5C5/R5R5: RPN and RSSI
of all the other base stations seen by the mobile in different cells
• C6C6/R6R6: RPN and RSSI
of all the other base stations seen by the mobile in different cells
• C7C7/R7R7: RPN and RSSI
of all the other base stations seen by the mobile in different cells
• C8C8/R8R8: RPN and RSSI
of all the other base stations seen by the mobile in different cells
C
3
C
3
R
3
R
3
/
C
4
C
4
R
4
R
4
C
5
C
5
R
5
R
5
/
C
6
C
6
R
6
R
6
C
7
C
7
R
7
R
7
/
C
8
C
8
R
8
R
8
