30 OI/266/FF/ADD-EN Rev. B | 2600T Series Pressure transmitters
266 Models - FOUNDATION Fieldbus
Cat. Error Block err HMI code PRTB_x_VALUE Status
Electronics errors PRIMARY SECONDARY TERTIARY QUATERNARY PDP_TRIM SP_TRIM
Memory Failure RB.Lost NV Data F116.023 BAD Device Failure No Limit
Electronic Interface error.
RB.Device Needs
Maintenance Soon
M030.020 GOOD_NC Non Specific No Limit
Non-Volatile memory burn error
RB.Device Needs
Maintenance Soon
M026.024 GOOD_NC Non Specific No Limit
Pressure sensor errors PRIMARY SECONDARY TERTIARY QUATERNARY PDP_TRIM SP_TRIM
Sensor Invalid PRTB.Sensor Failure F120.016 BAD Sensor Failure No Limit
Sensor Memory Fail PRTB.Sensor Failure F118.017 BAD Sensor Failure No Limit
P-dP Sensor Fail PRTB.Sensor Failure F114.000 BAD Sensor Failure No Limit
GOOD_NC Non
Specific No Limit
GOOD_NC Non
Specific No Limit
BAD Sensor Failure No Limit
GOOD_NC Non
Specific No Limit
Static Pressure Sensor Fail PRTB.Sensor Failure F112.001
UNCERTAIN Sensor
Conversion Not Accurate No
Limit
GOOD_NC Non
Specific No Limit
BAD Sensor Fail-
ure No Limit
UNCERTAIN Sensor Conver-
sion Not Accurate No Limit
BAD Sensor Fail-
ure No Limit
Sensor Temperature Fail PRTB.Sensor Failure F110.002
UNCERTAIN Sensor
Conversion Not Accurate No
Limit
BAD Sensor Fail-
ure No Limit
UNCERTAIN Sensor Conversion Not Accurate No Limit
NonVolatile memory burn error
RB.Device Needs
Maintenance Soon
M028.018 GOOD_NC Non Specific No Limit
Installation / start-up errors PRIMARY SECONDARY TERTIARY QUATERNARY PDP_TRIM SP_TRIM
Out of Service RB.Out of Service BAD Out of Service
Input Simulation Active PRTB.Local Override C088.030 GOOD_NC Non Specific No Limit
Replace Info
RB.Device Needs
Maintenance Soon
M020.042 GOOD_NC Non Specific No Limit
Process errors PRIMARY SECONDARY TERTIARY QUATERNARY PDP_TRIM SP_TRIM
Pressure Overrange PRTB.Other F104.032 BAD Non Specific No Limit GOOD_NC Non Specific No Limit BAD Non Specific No Limit
GOOD_NC Non
Specific No Limit
P-dP Out Of Limit PRTB.Other F102.004
UNCERTAIN Non Specific
No Limit
GOOD_NC Non Specific No Limit
UNCERTAIN Non Specific No
Limit
GOOD_NC Non
Specific No Limit
Static Pressure Out Of Limit PRTB.Other F100.005
UNCERTAIN Sensor Conver-
sion Not Accurate No Limit
GOOD_NC Non
Specific No Limit
UNCERTAIN Non
Specific No Limit
UNCERTAIN Sensor Conver-
sion Not Accurate No Limit
UNCERTAIN Non
Specific No Limit
Sensor Temperature Out Of
Limit
PRTB.Other S054.006
UNCERTAIN Sensor Conver-
sion Not Accurate No Limit
UNCERTAIN Non
Specific No Limit
UNCERTAIN Sensor Conversion Not Accurate No Limit
Max. Working Pressure
Exceeded
PRTB.Other M052.031 GOOD_NC Non Specific No Limit
