2600T Series Pressure transmitters | OI/266/FF/ADD-EN Rev. B 31
Cat. Error Block err HMI code PRTB_x_VALUE Status
Process errors PRIMARY SECONDARY TERTIARY QUATERNARY PDP_TRIM SP_TRIM
Primary Variable Out of Range
High Range
PRTB.Other S050.010 GOOD_NC Non Specific No Limit
UNCERTAIN engineering unit
range violation High Limit
GOOD_NC Non Specific No Limit
Low Range
UNCERTAIN engineering unit
range violation Low Limit
PILD Output
PILD Affect PV = 0
ADTB.Device Needs
Maintenance Soon
M018.038
GOOD_NC Non Specific No Limit
PILD Affect PV = 1
BAD Sensor
Failure No Limit
GOOD_NC Non
Specific No Limit
BAD Sensor Failure No Limit
PILD Changed Operating Conditions
PILD Affect PV = 0
ADTB.Device Needs
Maintenance Soon
M018.038
GOOD_NC Non Specific No Limit
PILD Affect PV = 1
BAD Sensor
Failure No Limit
GOOD_NC Non
Specific No Limit
BAD Sensor Failure No Limit
Out Of Service PRTB.Out of Service BAD Out of Service
Device troubleshooting Cat Error HMI code Description Possible Cause Suggested Actions Electronics errors
Memory Failure F116.023
The device data loaded at the start up are corrupted precluding the correct functionality of the device
Electronic memory corrupted The electronics must be replaced
Electronic Interface error. M030.020
Exchange of data between Electronics and Sensor have problems
Exchange of non-critical data between sensor and electronics is precluded due to problem in the transmitter circuit of the electronics or in receiver circuit of the sensor
Power cycle the device and retry the operation, if the error persist the electronics should be replaced
Non-Volatile memory burn error
M026.024
The device continue to work without problems but at the next power cycle the new configuration will be lost
Writings to the electronic non-Volatile Memory was not successful
The electronics should be replaced as soon as possible.
Pressure sensor errors
Sensor Invalid
Missing Primary Signal
F120.016
The primary signal of the sensor is no longer available. The transducer is not in a condition to generate a valid signal.
The sensor signal is not being updated correctly as a result of an electronics failure, sensor error or a poorly connected sensor cable.
Check cable connection, check sensor and if problem persists, the sensor must be replaced.
Invalid Sensor
Sensor and/or the connected electronics are incompatible
The sensor model/version is not longer compatible with the connected electronic version
The sensor must be replaced
Sensor Memory Fail F118.017
The data in the sensor memory are corrupted precluding the correct functionality of the device
Sensor memory corrupted The Sensor must be replaced
P-dP Sensor Fail F114.000
The sensor signal value is incorrect due to a mechanical failure
Mechanical damage to the sensor. Loss of fill fluid from the cell; ruptured diaphragm, broken sensor….
The Sensor must be replaced
Static Pressure Sensor Fail F112.001
The sensor signal value is incorrect due to a mechanical failure. Valid only for Differential pressure models
The circuitry for the sampling of the static pressure has failed.
The Sensor must be replaced
