32 OI/266/FF/ADD-EN Rev. B | 2600T Series Pressure transmitters
266 Models - FOUNDATION Fieldbus
Cat Error HMI code Description Possible Cause Suggested Actions
Pressure sensor errors
Sensor Temperature Fail F110.002
The measurement accuracy is decreased more than the acceptable error
The circuitry for the sampling of the temperature has failed.
The Sensor must be replaced
Non-Volatile memory burn error
M028.018
The device continue to work without problems but any replacement operation is compromised because the back-up configuration is not updated
Writings to the Sensor non-Volatile Memory was not successful
The Sensor should be replaced as soon as possible.
Installation / start-up errors
RB Out of Service
Device configured to be Out of Service or initializing
Resource Block is configured to be Out of Service
The TARGET MODE of the Resource Block must be switched in AUTO
Input Simulation Active
PdP simulation
C088.030
The Process Value is simulated to became the P-dP value measured in input
The P-dP Value in output is calculated from a value simulated in input
Use DD based configurator (AVB Professional - Hand held) to place device back into normal operating mode (Remove the input simulation)
Static Pressure simulation
The Process Value is simulated to became the Static Pressure value measured in input
The Static Pressure Value in output is calcu- lated from a value simulated in input
Sensor Temp simulation
The Sensor Temperature Value is simulated to became the measured Sensor Temperature value
The Sensor Temperature Value in output is calculated from a value simulated in input
Replace Info
Replace required – Both data direction valid
M020.042
The Replace operation is required after the changing of the electronics or of the sensor
The Electronics or the Sensor have been changed but the replacement operation has not been executed
The replacement operation must be executed: – Move the SW 1 of the electronics in position 1 (= Enable replace mode). – Select the SW 2 the element that has been changed between new Sensor or new electronics – Power Cycle the device – Move the SW 1 of the electronics in position 0
Replace required – FE to CB not applicable
The Replace operation is required after the changing of the electronics or of the sensor
The Electronics or the Sensor has been changed and a replacement operation for a new sensor has to be executed.
The replacement operation must be executed: Only electronics data can be copied into the sensor – Move the SW 1 to Enable replace mode (1) – Select with the SW 2 to New Sensor (1) – Power Cycle the device – Move the SW 1 to Disable replace mode (0)
Replace enabled – FE to CB not applicable
The Replace operation has been attempted but with wrong direction
The Electronics or the Sensor have been changed, The replacement has been enabled but with a wrong direction (SW 2 = 0)
Change the replacement direction (if possible) – The SW 1 is already set to Enable replace mode – Select with the SW 2 to New Sensor (1) – Power Cycle the device – Move the SW 1 to Disable replace mode (0)
Process errors
Pressure Overrange F104.032 An overpressure has been detected
This effect could be produced by other equipment on the process, (valves…). Exceeding the pressure range can cause reduced accuracy or mechanical damage to the diaphragm material and may require calibration/replacement.
The compatibility of pressure transmitter model and process conditions has to be checked. A different transmitter type could be required
