Process Station ABB FieldController 800
12
3.1 Inserting a D-PS or D-PS/RED resource
Select target position of new process station
→
insert over
a new process station can be inserted over the selected object
→ Insert under
a new process station can be inserted under the selected object
→ Insert next level
a new process station can be inserted one level deeper
The target position can be located at the next level below the configuration
element or (only in the case of next level insertion) on the configuration itself.
→ on target position and press left mouse button → OK
3.2 Inserting a task or redundant task
In the process station the actual programs run into the task. The programs are edited either using
Instruction Lists or Sequential Function Chart.
A redundant task has so-called redundancy data. These are data of the process image and of the
function blocks for which a data adjustment is performed after each cycle. This ensures that a re-
dundancy toggle can take place at any point in time.
So that the data of a redundant task are redundancy-capable, all variables of a redundant task
must be written in process image mode.
Not only the redundant task (TASK/RED), but also tasks of the previous type (TASK) can be con-
figured under the redundant resources. Thus only those functions of the user program which also
actually have to be redundant need to be configured redundantly within a redundant resource.
