Process Station ABB FieldController 800
42
6.5.3 State of the basic unit
On insertion into the hardware structure the FieldController is displayed with its basic unit. The
FieldController basic unit indicates whether the unit is active, inactive or faulty. Where a fault is
indicated, this is generally due to the unit not being detected at all, i.e. not being installed or being
impossible to address via the system bus.
dark gray The basic unit is activated.
light gray The basic unit is not activated
red The basic unit cannot be addressed
6.5.4 Status of the FieldController modules
The detailed picture of the module shows more detailed information on the modules of the
FieldController, so that these can be identified more easily.
The status of modules in the FieldController is marked by a colored triangle.
No module found (red exclamation mark)
A module is configured in this slot, but not present in the FieldController.
Wrong module type (orange exclamation mark)
The module type configured in the hardware structure does not match the installed module type
Forced channels (green exclamation mark)
At least one of the module's channels has been forced. See Engineering Manual, System Con-
figuration, Commissioning, Forcing inputs and outputs.
Config fault (red exclamation mark)
The Profibus-Master has detected a configuration fault. See Engineering Reference Manual,
Communications and Fieldbusses, Profibus, Profibus-DP States
Parameter fault (red exclamation mark)
The Profibus-Master has a detected a parameter fault. See Engineering Reference Manual,
Communications and Fieldbusses, Profibus, Profibus-DP States
Diagnostic value detected (blue exclamation mark)
A diagnostic value has been recorded for the slave or for a module of the slave. The diagnostic
value is shown in the list in the slave detail view, below the graphical representation. See Engi-
neering Reference Manual, Communications and Fieldbusses, Profibus, Diagnostic Data.
