ABB AC 800F

Process Station ABB FieldController 800
25
Communication link Required no. of interface objects
Link module DCO01 1
Tele Control Library 4
Profibus Master 2
Profibus Slave 0
Modbus Master 2
Modbus Slave 2
Protronic / Freelance 100 1
Sartorius 1
Send 1
Receive 1
Interbus Send 1
Interbus Receive 1
I/O bus (CAN)
Enable This configures the usage of slot F1 in the FieldController. If a CAN module
is installed in that slot, then the CAN bus must be activated here. If any
other module is installed in slot F1, then the CAN bus must be deactivated.
Transmission
rate Select a transmission rate of 100 or 500 Kbit/s of the station bus (default
500 Kbit/s). The transmission rate is closely linked to the distance between
two stations of one process station.
Transmission rate Distance to last I/O unit
500 Kbit/s 80m
100 Kbit/s
400m
I/O Bus Select the I/O protocol
Redundancy Default, - I/O EPROM’s capable of redundant operation must be
plugged on all I/O modules.
Not redundant
As of version 6.1 (AC 800F only) not supported.
