Page #71 background imageLoading...
Page #71 background image
05 TRANSPORTATION, STORAGE AND DISPOSAL
3BHS213401 E01 REV H ACS1000 AIR-COOLED USER MANUAL 69/184
5.1 Safety
5.2 Transport conditions
The transport conditions for the drive are based on "IEC 60721-3-2 Classification of
environmental conditions - Part 3-2: Classification of groups of environmental parameters and
their severities - Transportation and Handling" [23].
- Transport conditions: 2K12 / 2B1 / 2C2 / 2S5 / 2M4
- Maximum transport time: 2 months
5.3 Unpacking and inspection
1. Remove all packaging material carefully.
2. Check the drive and accompanying equipment for damages.
3. Compare the complete delivery with the purchase order and the packing list.
4. If parts are missing or damaged, immediately inform the shipping company and the ABB
service organization.
Note: It is recommended to photograph the damages and send the photographs to ABB.
5.4 Lifting and transportation
5.4.1 General notes on transportation
NOTICE
The drive must only be handled by personnel who are skilled and experienced in
unpacking and transporting heavy equipment.
It is recommended to have the following information, which is in "Appendix C -
mechanical drawings", at hand before transporting the cabinet:
- “Layout drawing” document
- “Fixing and Lifting details” document
Risk of component damage!
- Do not lift and move the drive or a transport unit using a forklift. The frame of
the cabinets could be damaged. If a crane is not available, contact ABB for
instructions on other means of moving.
- Transport the cabinet in upright position.
- To ensure that dirt cannot enter, keep the doors closed. Metallic dust in
particular can cause damage and failure when the drive is energized
- If the drive is delivered in several transport units, do not lift and move the drive
by crane after the transport units have been joined. Use appropriate transport
means eg, heavy load hydraulic rollers or air cushions. If in doubt, contact ABB
for instructions.
