ABB ACS800-04M - Frame Size R7 Units with Bottom Exit (+H352); Delivery Check

Mechanical installation of non-pre-assembled units (ACS800-04M)
49
Frame size R7 units with bottom exit (+H352)
Delivery check
Check that there are no signs of damage. Before attempting installation and
operation, check the information on the type designation label of the drive to verify
that the unit is of the correct type.
ACS800-04M of frame size R7 with bottom exit
Package Parts Assembling drawing / reference to instruction
ProE code 64770306 D
Basic unit (type code ACS800-0M4-xxxx-x+H352)
-
Refer to section Assembling procedure on page 53.
Drive control unit (RDCU)
See RDCU Drive Control Unit Hardware Manual
[3AFE64636324 (English)].
Drive module
Front
RDCU drive control unit
