Mechanical installation of non-pre-assembled units (ACS800-04M)
98
Item packages of frame size R8 with busbars on the short side
ACS800-04M with busbars on the short side (frame size R8)
Package Parts Assembling drawing / reference to instruction
ProE code 64772023 E
Basic unit (type code ACS800-04M-xxxx-x+H355+H360)
-
Refer to section Assembling procedure for units with
busbars on the short side (+H360) on page 104.
Drive control unit
(RDCU)
See RDCU Drive Control Unit Hardware Manual
[3AFE64636324 (English)].
Drive module
Front
RDCU drive control unit
