CONTROLMASTER CM10 | UNIVERSAL PROCESS CONTROLLER, DIN | CI/CM10-EN REV. C
21
Icon Number/
Message
Possible cause Suggested action
Temporary or permanent failure of analog to
digital converter on the main I/O board.
Cycle power to controller.
If problem persists replace main I/O board.
Contact local service organization.
Broken sensor leads, defective input source
or input signal out of permitted range.
Check wiring.
Check input source.
Check if input signal is outside permitted limits.
Remote Setpoint. Broken sensor leads,
defective input source or input signal out of
permitted range.
Check wiring.
Check input source.
Check if input signal is outside permitted limits.
Error in Cold junction measurement
defective sensor.
Check cold junction device is correctly fitted.
Replace CJ sensor.
variable. Broken sensor leads, defective
input source or input signal out of permitted
range.
Check wiring.
Check input source.
Check if input signal is outside permitted limits.
position feedback. Broken sensor leads,
defective input source or input signal out of
permitted range.
Check wiring.
Check input source.
Check if input signal is outside permitted limits.
NV Error
Proc Bd
Failure of non-volatile memory on processor/
display board or permanent corruption of its
data.
Check all configuration parameters and correct any errors.
Acknowledge error.
If problem persists contact local service organization.
