ABB ControlMaster CM10 Commissioning Instructions

CONTROLMASTER CM10 | UNIVERSAL PROCESS CONTROLLER,  DIN | CI/CM10-EN REV. C
25
Menu Menu
Input/Output Control
Analog Inputs
Analog Input 1 (2)
Analog Outputs
Analog Output 1
Digital I/O
Digital IO 1 (2)
Relays
Relay 1 (4)
Loop 1 Setpoints
Low Limit
High Limit
No. of Local SP’s
Local Setpoint 1
Track M ode
RSP Ratio
RSP Bias
RSP Fault Action
Default Setpoint
Ramp Mode
Ramp Rate
Select Sources
Loop 1 Control
Control Type
Control Action
On/Off Hysteresis
Autotune
PID
Loop 1 Output
Limits
Failure Actions
A/M Select
Sources
Slew Rate
Loop 1 Split O/P
Min Input 1
Min OP 1
Max Input 1
Max OP 1
Min Input 2
Min OP 2
Max Input 2
Max OP 2
Loop 1 Time Prop
Cycle Time 1
Cycle Time 2
Continued
overleaf
Exit Select Exit Select
