ABB DCS 600 - Filter in a Grounded Line (Earthed TN or TT Network); Single - Phase Filters for Field Supply; Three - Phase Filters

II F 2-22
Three - phase filters
EMC filters are necessary to fulfill EN 50081 if a
converter shall be run at a public low voltage line,
in Europe for example with 400 V between the
phases. Such lines have a grounded neutral
conductor. ABB offers suitable three - phase
filters for 400 V and 25 A....600 A and 500 V filters
for 440 V lines outside Europe.
Lines with 500 V to 1000 V are not public. They
are local lines inside factories, and they do not
supply sensitive electronics. Therefore convert-
ers do not need EMC filters if they shall run with
500 V and more.
Converter type Rated dc current Filter type Dimensions
L x W x H
xxx = Voltage
[A] [kg] [mm]
DCS600-0025-x1 25 NF3-xxx-25 3 200x150x65
DCS600-0050-x1 50 NF3-xxx-50 3.1 200x150x65
DCS600-0075-x1 75 NF3-xxx-64 3.1 200x150x65
DCS600-0100-x1 100 NF3-xxx-80 9.5 400x170x90
DCS600-0140-x1 140 NF3-xxx-110 9.5 400x170x90
DCS600-0200-x1 200 NF3-xxx-320 28 450x285x171
DCS600-0250-x1 250 NF3-xxx-320 28 450x285x171
DCS600-0350-x1 350 NF3-xxx-320 28 450x285x171
DCS600-0450-x1 450 NF3-xxx-600 49 590x305x158
DCS600-0520-x1 520 NF3-xxx-600 49 590x305x158
DCS600-0700-x1 700 NF3-xxx-600 49 590x305x158
DCS600-0900-x1 900 NF3-xxx-1000 90 610x305x198
DCS600-1200-x1 1200 NF3-xxx-1000 90 610x305x198
DCS600-1500-x1 1500 NF3-xxx-1600 130 840x465x210
DCS600-2000-x1 2000 NF3-xxx-1600 130 840x465x210
DCS600-2500-x1 2500 NF3-xxx-2500 200 955x520x293
The filters 25... 2500 A are available for 440 V and 500 V, and the filters
600...2500 A are available for 690 V too.
➊ The filters can be optimized for the real motor currents:
I
Filter
= 0.8 • I
MOT max
; the factor 0.8 respects the current ripple.
➊
Weight
appr.
Converter type of dc current Filter type Dimensions
field supply unit U
max
= 250 V
L x W x H
[A] [kg] [mm]
SDCS-FEX-1 6 NF1-250-8 0.7 139x105x59
SDCS-FEX-2 8 NF1-250-8 0.7 139x105x59
SDCS-FEX-2 16 NF1-250-20 1.0 139x105x59
DCF 503-0050 50 NF1-250-55 1.8 230x115x60
DCF 504-0050 50 NF1-250-55 1.8 230x115x60
further filters for 12 NF1-250-12 0.9 139x105x59
30 NF1-250-30 1.0 148x105x57
➊ The filters can be optimized for the real field currents: I
Filter
= I
Field
➊
Weight
appr.
Filter in a grounded line (earthed TN or TT
network)
The filters are suitable for grounded lines only, for
example in public European 400 V lines. Accord-
ing to EN 61800-3 filters are not needed in
insulated industrial lines with own supply trans-
formers. Furthermore they could cause safety
risks in such floating lines (IT networks).
Single - phase filters for field supply
Many field supply units are single - phase con-
verters for up to 50 A excitation current. They can
be supplied by two of the three input phases of
the armature supply converter. Then a field
supply unit does not need its own filter.
If the phase to neutral voltage shall be taken
(230V in a 400 V line) then a separate filter is
necessary. ABB offers such filters for 250 V and
6...30 A.
