ABB DCS 600 - Auxiliary Status Word; DI Status Word; Main Status Word

II F 3-12
Table 3.7/4: Main Status Word
Table 3.7/5: Auxiliary Status Word
Auxiliary Status Word (8.02)
ABB Drive Profile Control Word
Bit Name Function
0 LOGG_DATA_READY
1 OUT_OF_WINDOW
2
EMERG_STOP_CO-
AST
3 reserved (reserved)
4 ON_DISABLED
External interlocking
OFF1_N (Digital input
selected by 15.14)
prevents the run
5 SYNC_RDY
Position counter
synchronous ready status
6 FEX1_ACK FEX 1 acknowledge
7 FEX2_ACK FEX 2 acknowledge
8 reserved (reserved)
9 LIMITING see signals 8.03, 8.04
10 TORQ_CONTROL Drive is torque controlled
11 ZERO_SPEED Motor speed actual is zero
12 EMF-SPEED
EMF speed feedback
selected
13 FAULT_OR_ALARM Fault or alarm of drive
14 DRIVE_DIR_ASW
Negative drive direction
active
15 AUTO_RECLOSING
auto reclosing logic
activated
Table 3.7/6: DI Status Word
Main Status Word (8.01)
ABB Drive Profile Control Word
Bit Name Function
0 RDY_ON ready to close the contactor
1 RDY_RUN ready to generate torque
2RDY_REF
torque control operating
(running)
3 TRIPPED
indication of fault in DC
Device
4 OFF_2_STA_N 1: No OFF2 active
5 OFF_3_STA_N 1: No OFF3 active
6 ON_INHIBITED Switch on inhibited
7ALARM
indication of alarm in DC
Device
8 AT_SETPOINT
Setpoint/act.value monitoring
in the tolerance
9REMOTE
1:Remote control / 0:Local
control
10 ABOVE_LIMIT
speed treshold value (50.10)
reached
11 reserved (reserved)
12 reserved (reserved)
13 reserved (reserved)
14 reserved (reserved)
15 reserved (reserved)
DI Status Word (8.05)
Digital input status word of DCS 600 MultiDrive
Bit Name Function
0 DI 1 configurable
1 DI 2 configurable
2 DI 3 configurable
3 DI 4 configurable
4 DI 5 configurable
5 DI 6 configurable
6 DI 7 configurable
7 DI 8 configurable
8 DI 9 programmable Drive, if SDCS-IOE-1 is present
9 DI 10 programmable Drive, if SDCS-IOE-1 is present
10 DI 11 programmable Drive, if SDCS-IOE-1 is present
11 DI 12 programmable Drive, if SDCS-IOE-1 is present
12 DI 13 programmable Drive, if SDCS-IOE-1 is present
13 DI 14 programmable Drive, if SDCS-IOE-1 is present
14 DI 15 programmable Drive, if SDCS-IOE-1 is present
15 IOE1 1: SDCS-IOE-1 is connected to SDCS-CON-1
configurable: The DI can be selected for several converter functions; inversion function is available; in addition, it may be used for
application running.
available for programmable Drive: The DI is not selectable for converter functions, but is available for application programming.
