ABB DCS880 Service Manual

11
Introduction to this manual
3ADW000488R0101 DCS880 Service manual e a
Type code
The type code contains information on the specification and configuration of the drive. The first digits from left
show the basic configuration (e.g. DCS880-S01-2000). The optional selections are given thereafter on the name
plate by plus code. The main selections are described below. Not all selections are available for all types.
The drive’s basic type code: DCS880-aab-cccc-ddef
Product family:
DCS880
Product type:
aa
= S0
Standard converter module
= R0
Rebuild kit
= E0
Panel solution
= A0
Enclosed converter
Bridge type:
b
= 1
Single bridge (2-Q)
= 2
2 anti-parallel bridges (4-Q)
Module type:
cccc
=
Rated DC current (IP00)
Rated AC voltage:
dd
= 04
100 V
AC
… 415 V
AC
= 05
100 V
AC
… 525 V
AC
= 06
270 V
AC
… 600 V
AC
= 07
315 V
AC
… 690 V
AC
= 08
360 V
AC
… 800 V
AC
= 10
450 V
AC
… 990 V
AC
= 12
540 V
AC
… 1200 V
AC
Power connection:
e
= X
Standard H1 … H7
= L
Left side H8
= R
Right side H8
Revision code:
f
= 0
1
st
generation
Field exciter
configuration:
+0S163
+S164
H1 ... H4 without OnBoard field exciter
H5 and H6 with internal field exciter, supply external
(H5 and H6: 25 A, Rebuild kit: 16 A/25 A)
Fan voltage:
Standard
+S171
Size H4
Fan voltage: 230 V/1-ph
Fan voltage: 115 V/1-ph
Application
programming
+S551
Memory unit including drive application programming license
SDCS-DSL-H1x:
+S521
+S522
+S523
1 DCSLink channel, 0 channels optical power link SDCS-DSL-H10
1 DCSLink channel, 2 channels optical power link SDCS-DSL-H12
1 DCSLink channel, 4 channels optical power link SDCS-DSL-H14
Voltage
measurement:
+S185
SDCS-PIN-H51 configured for 20 V
AC
... 100 V
AC
(H6 ... H8)
Control panel:
+0J404
+J428
+J429
Without control panel
daisy-chain option DPI-H01 kit
Bluetooth control panel ACS-AP-W
The technical data and specifications are valid as of going to press. ABB reserves the right to make subsequent
alterations.

ABB DCS880 Specifications

General

Control Type	Digital
Voltage Range	Up to 1200 V DC
Control Principle	Field-oriented control
Field Supply	Integrated
Communication Protocols	CANopen
Cooling	Air
Protection Class	IP00, IP20, IP21, IP54
Protection Features	Overvoltage, overtemperature, short circuit, earth fault
Rated Voltage	230 to 1200 V DC
Supply Voltage	380 ... 690 V AC
Input Voltage Range	230 to 690 V AC
Control Mode	Speed, Torque
