106 Communication protocol
The format of the input assembly is:
10 DATA OUT 3 Value (Low Byte)
11 DATA OUT 3 Value (High Byte)
12 DATA OUT 4 Value (Low Byte)
13 DATA OUT 4 Value (High Byte)
14 DATA OUT 5 Value (Low Byte)
15 DATA OUT 5 Value (High Byte)
16 DATA OUT 6 Value (Low Byte)
17 DATA OUT 6 Value (High Byte)
18 DATA OUT 7 Value (Low Byte)
19 DATA OUT 7 Value (High Byte)
20 DATA OUT 8 Value (Low Byte)
21 DATA OUT 8 Value (High Byte)
22 DATA OUT 9 Value (Low Byte)
23 DATA OUT 9 Value (High Byte)
24 DATA OUT 10 Value (Low Byte)
25 DATA OUT 10 Value (High Byte)
Instance 172
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Run-
ning1
(Fwd)
Faulted
1
2 Speed Actual (Low Byte)
3 Speed Actual (High Byte)
4 Torque Actual (Low Byte)
5 Torque Actual (High Byte)
Instance 122
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
