Communication protocol 147
 Drive parameter object, Class 90h
With FDNA-01, drive parameters can also be accessed via explicit
messaging. Explicit messaging makes use of objects consisting of
three parts: class, instance and attribute.
Note: When using the Drive parameter object to update the
fieldbus configuration groups, changes to the fieldbus configuration
will only take effect when the module is powered up the next time
or when a ‘Fieldbus Adapter parameter refresh’ is given.
Class is always 144 (90h). Instance and attribute correspond to the
drive parameter group and index in the following way:
For example, parameter 99.01 is accessed as follows:
22 Speed
Scale
Get, Set Speed scaling factor. See
parameter description 10 ODVA
SPEED SCALE.
UINT8
24 Torque
Scale
Get, Set Torque scaling factor. See
parameter description 11 ODVA
TORQUE SCALE.
UINT8
29 Ref From
Net
Get Reflecting attribute 4 BOOL
• Instance = Parameter group (0…99)
• Attribute = Parameter index (01…99)
• Class = 144 = 90h
• Instance = 99 = 63h
• Attribute = 1 = 01h
# Attribute
name
Services Description Data
type
