Communication protocol 129
The format of the input assembly is:
8 Drive Profile 32-bit Reference 2 word (Low Byte)
9 Drive Profile 32-bit Reference 2 word
10 Drive Profile 32-bit Reference 2 word
11 Drive Profile 32-bit Reference 2 word (High Byte)
Instance 872
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Drive Profile 32-bit Status word (Low Byte)
1 Drive Profile 32-bit Status word
2 Drive Profile 32-bit Status word
3 Drive Profile 32-bit Status word (High Byte)
4 Drive Profile 32-bit Actual 1 word (Low Byte)
5 Drive Profile 32-bit Actual 1 word
6 Drive Profile 32-bit Actual 1 word
7 Drive Profile 32-bit Actual 1 word (High Byte)
8 Drive Profile 32-bit Actual 2 word (Low Byte)
9 Drive Profile 32-bit Actual 2 word
10 Drive Profile 32-bit Actual 2 word
11 Drive Profile 32-bit Actual 2 word (High Byte)
Instance 822
