The format of the input assembly is:
22 DATA OUT 6 Value (Low Byte)
23 DATA OUT 6 Value (High Byte)
24 DATA OUT 7 Value (Low Byte)
25 DATA OUT 7 Value (High Byte)
26 DATA OUT 8 Value (Low Byte)
27 DATA OUT 8 Value (High Byte)
28 DATA OUT 9 Value (Low Byte)
29 DATA OUT 9 Value (High Byte)
30 DATA OUT 10 Value (Low Byte)
31 DATA OUT 10 Value (High Byte)
Instance 972
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Drive Profile 32-bit Status word (Low Byte)
1 Drive Profile 32-bit Status word
2 Drive Profile 32-bit Status word
3 Drive Profile 32-bit Status word (High Byte)
4 Drive Profile 32-bit Actual 1 word (Low Byte)
5 Drive Profile 32-bit Actual 1 word
6 Drive Profile 32-bit Actual 1 word
7 Drive Profile 32-bit Actual 1 word (High Byte)
8 Drive Profile 32-bit Actual 2 word (Low Byte)
9 Drive Profile 32-bit Actual 2 word
10 Drive Profile 32-bit Actual 2 word
11 Drive Profile 32-bit Actual 2 word (High Byte)
12 DATA IN 1 Value (Low Byte)
13 DATA IN 1 Value (High Byte)
Instance 922
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
