Start-up 51
5109 FB PAR 9
(INPUT NUM PARS)
10 Must always be set to 10, except as
provided in Appendix A – Varying
the number of drive parameters.
5110 FB PAR 10
(ODVA SPEED SCALE)
128 Sets the scaling as 1 rpm for the
ODVA speed reference.
5111 FB PAR 11
(ODVA TORQUE SCALE)
128 Sets the scaling as 1 Nm for the
ODVA torque reference.
5401 FBA DATA IN 1 104 Current
5402 FBA DATA IN 2 107 DC bus voltage
5403 FB DATA IN 3
…5410 DATA IN 10
0
5501 FBA DATA OUT 1 2205 Acceleration time 2
5502 FBA DATA OUT 2 2206 Deceleration time 2
5503 FB DATA OUT 3
…5510 DATA OUT 10
0
51.27 FBA PAR REFRESH 1 = REFRESH Validates the FDNA-01
configuration parameter settings.
1001 EXT1 COMMANDS 10 = COMM Selects the fieldbus interface as the
source of the start and stop
commands for external control
location 1.
1003 DIRECTION 3 = REQUEST Allows control of rotation direction.
1103 REF1 SELECT 8 = COMM Selects the fieldbus reference 1 as
the source for speed reference.
1604 FAULT RESET SEL 8 = COMM Selects the fieldbus interface as the
source for the fault reset signal.
9904 MOTOR CTRL MODE 2 = VECTOR:
TORQ
Selects the vector control mode as
the motor control mode.
1002 EXT2 COMMANDS 10 = COMM Selects the fieldbus interface as the
source of the start and stop
commands for external control
location 2.
1102 EXT1/EXT2 SEL 8 = COMM Enables external control location
1/2 selection through the fieldbus.
1106 REF2 SELECT 8 = COMM Selects the fieldbus reference 2 as
the source for torque reference.
Drive parameter Setting for
ACS355 drives
Description
