Start-up 53
5106 FB PAR 6
(OUTPUT INSTANCE)
23 Selects the ODVA extended speed
and torque control output instance.
5108 FB PAR 8
(INPUT INSTANCE)
73 Selects the ODVA extended speed
and torque control input instance.
5110 FB PAR 10
(ODVA SPEED SCALE)
128 Sets the scaling as 1 rpm for the
ODVA speed reference.
5111 FB PAR 11
(ODVA TORQUE SCALE)
128 Sets the scaling as 1 Nm for the
ODVA torque reference.
51.27 FBA PAR REFRESH 1 = REFRESH Validates the FDNA-01
configuration parameter settings.
1001 EXT1 COMMANDS 10 = COMM Selects the fieldbus interface as
the source of the start and stop
commands for external control
location 1.
1003 DIRECTION 3 = REQUEST Allows control of rotation direction.
1103 REF1 SELECT 8 = COMM Selects the fieldbus reference 1 as
the source for speed reference.
1604 FAULT RESET SEL 8 = COMM Selects the fieldbus interface as
the source for the fault reset
signal.
9904 MOTOR CTRL MODE 2 = VECTOR:
TORQ
Selects the vector control mode as
the motor control mode.
1002 EXT2 COMMANDS 10 = COMM Selects the fieldbus interface as
the source of the start and stop
commands for external control
location 2.
1102 EXT1/EXT2 SEL 1 = DI1 Selects digital input DI1 as the
source for the external control
location EXT1/EXT2 selection.
1106 REF2 SELECT 8 = COMM Selects the fieldbus reference 2 as
the source for torque reference.
1601 RUN ENABLE 7 = COMM Selects the fieldbus interface as
the source for the inverted Run
enable signal (Run disable).
1)
Read-only or automatically detected/set
Drive parameter Setting for
ACS355 drives
Description
