66 Start-up
The table below gives the recommended drive parameter settings.
Drive parameter Setting for
ACS880 drives
Description
50.01 FBA A enable 1 = Enable Enables communication between
drive and adapter module.
50.04 FBA A ref1 type 4 = Speed Selects speed as the fieldbus A
reference 1 type.
50.05 FBA A ref2 type 3 = Torque Selects torque as the fieldbus A
reference 2 type.
51.01 FBA type DeviceNet
1)
Displays the type of the adapter
module.
51.02 MAC ID 6 Defines the MAC ID number of the
adapter module.
51.03 Baud rate 0 = 125kbit/s Sets the baud rate for the DeviceNet
interface.
51.06 Output instance 902 Selects the ABB Drives profile with
speed and torque plus drive
parameters output instance.
51.07 Output num pars 10 Must always be set to 10. For
exceptions, see Appendix A –
Varying the number of drive
parameters.
52.01 FBA data in1 1.7 Motor current - MSW
52.02 FBA data in2 0 = None Motor current - LSW
52.03 FBA data in3 1.11 DC voltage - MSW
52.04 FBA data in4 0 = None DC voltage - LSW
52.05 FBA data in5…
52.10 FBA data in10
0 = None
53.01 FBA data out1 23.12 Acceleration time - MSW
53.02 FBA data out2 0 = None Acceleration time - LSW
53.03 FBA data out3 23.13 Deceleration time - MSW
53.04 FBA data out4 0 = None Deceleration time - LSW
53.05 FBA data out5…
53.10 FBA data out10
0 = None
51.27 FBA par refresh 1 = Configure Validates the FDNA-01 configuration
parameter settings.
