68 Start-up
The table below gives the recommended drive parameter settings.
Drive parameter Setting for
ACS880 drives
Description
50.01 FBA A enable 1 = Enable Enables communication between
drive and adapter module.
50.04 FBA A ref1 type 4 = Speed Selects Speed as the fieldbus A
reference 1 type.
50.05 FBA A ref2 type 3 = Torque Selects Torque as the fieldbus A
reference 2 type.
51.01 FBA type DeviceNet
1)
Displays the type of the adapter
module.
51.02 MAC ID 6 Defines the MAC ID number of the
adapter module.
51.03 Baud rate 0 = 125kbit/s Sets the baud rate for the DeviceNet
interface.
51.06 Output instance 23 Selects the ABB Drives profile with
speed and torque plus drive
parameters output instance.
51.07 Output num pars 10 Must always be set to 10. For
exceptions, see Appendix A –
Varying the number of drive
parameters.
51.27 FBA par refresh 1 = Configure Validates the FDNA-01 configuration
parameter settings.
19.11 Ext1/Ext2 selection 3 = DI1 Selects digital input DI1 as the
source for the external control
location EXT1/EXT2selection.
19.12 Ext1 control mode 1 2 = Speed Selects speed control as the control
mode 1 for external control location
EXT1.
19.14 Ext2 control mode 1 3 = Torque Selects torque control as the control
mode 1 for external control location
EXT2.
20.01 Ext1 commands 12 = Fieldbus A Selects fieldbus interface A as the
source of the start and stop
commands for external control
location EXT1.
