Start-up 75
7. Add your DeviceNet scanner to an RSLogix 5000 project. You
should get new Controller Tags Local:<slot>:I and
Local:<slot>:O. You can use them to access the data as
mapped above:
• Local:<slot>:O.Data[0] is the Control word
• Local:<slot>:O.Data[1] is the Reference
• Local:<slot>:I.Data[0] is the Status word
• Local:<slot>:I.Data[1] is the Actual value
Note: You may need to change the value of
Local:<slot>:O.CommandRegister.Run or
Local:<slot>:I.CommandRegister.Run to 1.
