ABB FDNA-01 User Manual

78 Communication profiles
The figure below illustrates the operation of the profiles:
The following sections describe the Control word, the Status word,
references and actual values for the ODVA AC/DC drive and ABB
Drives communication profiles. Refer to the drive manuals for
details on the native profiles.
FDNA-01 Drive
FDNA-01 profile
selection:
ABB Drives profile
Data conversion
ODVA AC/DC
Native profile
(eg, DCU,
FBA)
Data conversion
ODVA AC/DC
ABB Drives
Drive-specific profile
1)
(with 16-bit words)
Transparent32
Drive-specific profile
1)
(with 32-bit words)
DeviceNet
network
Transparent16
1)
Can be used if the native profile is supported by the drive.
Native profile
(eg, DCU,
FBA)

ABB FDNA-01 Specifications

General

ABB Type Designation	FDNA-01
Manufacturer	ABB
Input Voltage	24 VDC
Protection Class	IP20
Ordering Number	3BSE018160R1
Category	Control Unit
Operating Temperature	55 °C
Storage Temperature	-40°C to +70°C
Humidity	95% RH (non-condensing)
